产品简介
该系列产品是在GJB599Ⅲ系列基础上,采用12芯、24芯MT接触件发展成的一种耐环境高密度圆形光纤连接器。采用三级引导定位,具有五键识别、防错插、防斜插、盲插及接触件取卸方便等特点。外壳体可选用不同的材料及镀层以适应不同的环境要求。MT接触件可免工具取卸。
主要技术指标
机械性能
● 机械寿命:500次循环插拔
● 冲击:加速490m/s 2 ,11ms
● 振动:10~2000Hz,功率谱密度0.6g 2/Hz
环境性能
● 温度范围:-40℃~+80℃
● 盐雾: K类:500h F类:48h W类:200h MW类:192h(酸性大气)
光学性能
● 插入损耗:≤0.6dB
北亿纤通 | F-tone Networks
企业邮箱:该邮件地址已受到反垃圾邮件插件保护。要显示它需要在浏览器中启用 JavaScript。
企业手机:19081343401
企业电话:028-85255257
企业传真:028-85977702
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
