产品简介
● 性能符和ARINC801标准
● 推拉式插拔分离
● 三键定位,有盲插和防错插功能
● 应用领域:航天系统、船舶、航空等
主要技术指标
机械性能
● 机械寿命:500次
● 机械分离力:≤50N
● 冲击:980m/s²,持续时间6ms
● 振动:10Hz~2000Hz,功率谱密度0.4g²/Hz
环境性能
● 温度范围:-55℃~+125℃
● 盐雾:96h
光学性能
● 插入损耗:≤0.6dB
+86-028-85255257
产品简介
● 性能符和ARINC801标准
● 推拉式插拔分离
● 三键定位,有盲插和防错插功能
● 应用领域:航天系统、船舶、航空等
主要技术指标
机械性能
● 机械寿命:500次
● 机械分离力:≤50N
● 冲击:980m/s²,持续时间6ms
● 振动:10Hz~2000Hz,功率谱密度0.4g²/Hz
环境性能
● 温度范围:-55℃~+125℃
● 盐雾:96h
光学性能
● 插入损耗:≤0.6dB
北亿纤通 | F-tone Networks
企业邮箱:该邮件地址已受到反垃圾邮件插件保护。要显示它需要在浏览器中启用 JavaScript。
企业手机:19081343401
企业电话:028-85255257
企业传真:028-85977702
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
