产品简介
● 性能符和ARINC801标准
● 推拉式插拔分离
● 三键定位，有盲插和防错插功能
● 应用领域：航天系统、船舶、航空等
主要技术指标
机械性能
● 机械寿命：500次
● 机械分离力：≤50N
● 冲击：980m/s²，持续时间6ms
● 振动：10Hz～2000Hz，功率谱密度0.4g²/Hz
环境性能
● 温度范围：-55℃～+125℃
● 盐雾：96h
光学性能
● 插入损耗：≤0.6dB
YFP脱落光纤连接器
北亿纤通 | F-tone Networks
企业邮箱：该邮件地址已受到反垃圾邮件插件保护。要显示它需要在浏览器中启用 JavaScript。
企业手机：19081343401
企业电话：028-85255257
企业传真：028-85977702
